Request For Our Latest Prices on Monel K500 Stud Bolts in Da Nang, Vietnam!
Poang Fasteners is a reputable manufacturer and supplier located in Da Nang, Vietnam, specializing in high-quality Monel K500 Stud Bolts that are perfect for tough industrial and marine environments. These stud bolts are highly regarded for their outstanding corrosion resistance, impressive strength, and durability, making them a go-to choice for challenging conditions like seawater exposure, chemical handling, and high-stress applications. With a commitment to precision and strict adherence to international quality standards, Poang Fasteners guarantees that every Monel K500 Stud Bolt provides reliable performance, accurate dimensions, and a long lifespan. The company has earned a solid reputation as a trusted provider of advanced fastening solutions around the globe.
Monel K500 Stud Bolts are made from a nickel-copper alloy, enhanced with small amounts of aluminum and titanium, which give them age-hardening properties that boost their strength and hardness. This unique composition ensures excellent resistance to corrosion, stress cracking, and oxidation, even in the harshest environments. On a mechanical level, these stud bolts showcase high tensile and yield strength, remarkable toughness, and exceptional fatigue resistance. Their ability to maintain structural integrity under intense stress and temperature fluctuations makes them ideal for critical applications.
| Element | Content (%) |
| Nickel, Ni | 63.0-70.0 |
| Silicon, Si | .50 max |
| Carbon, C | .25 max |
| Sulphur, S | .01 max |
| Copper, Cu | – |
| Iron, Fe | 2.0 max |
| Manganese, Mn | 1.5 max |
| Properties | Metric | Imperial |
| Tensile strength(annealed) | 517-620 MPa | 75-90 ksi |
| Yield strength | 172-345 MPa | 25-50 ksi |
| Modulus of elasticity | 179 GPa | 26000 ksi |
| Poisson’s ratio | 0.32 | 0.32 |
| Specification | ASTM B865, F467 / ASME SB865, SF467 |
| Standard | all International Standards and ASTM, DIN, BS |
| Size | M3 – M56 | 3/6″ to 2″ | Custom Sizes |
| Length | 3 mm to 200 mm | Custom Sizes |
| DIN Standard | DIN 931, DIN 933, DIN 912, DIN 934, DIN 6923, DIN 603, DIN 7981, DIN 970, DIN916, DIN 7982, DIN 7985, DIN 913 |
| Form | Hex, Threading, Square, Round as per Gauge Etc. |
| Threads | Unless otherwise specified, the threads shall be rolled or cut and tapped horizontally or vertically |
| Threads available | UNF, BSW, BSF, METRIC, UNC, or as required |
| Threads Configuration | ASME B1.1 2A/3A – 2B/3B Inch Unified Threads and B1.13M 6h-6G Metric Coarse Threads |
| UTS | NPT, UNS, UNF, UNC, UNEF, NPTF |
| Test Certificate | As per EN 10204 / 3.1 Manufacturer Test Certificate, PED 97/23/EC Certified, Merkblatt AD 2000 W2 Certified |
| ISO | ISO 4033, ISO 4032, ISO 7380, ISO 4017, JIS standards |
| Threads | METRIC, BSW, UNC, UNF, BSF or as required |
| Surface Coating | Cadmium Coating Hot Dipped Galvanizing Coating Ptfe Coated Phosphate Coating Teflon Coating Xylon Coating Zinc Coating |
To satisfy our clients needs by providing high quality products at competitive price as per the schedule and to maintain long term relationship with our clients.
Monel K500 stud bolts are widely used in marine engineering, chemical processing and oil exploration because of their high strength and resistance to corrosive substances. They are especially suitable for marine and offshore structures, and for critical parts such as pumps, valves and industrial equipment which are exposed to harsh conditions.
You’ll find Monel K500 Stud Bolts widely used in marine engineering, offshore platforms, and shipbuilding, especially for components that face seawater and other tough conditions. They’re also essential in chemical processing plants, pumps, and valves that deal with corrosive substances. The oil and gas industry relies on them for drilling rigs, heat exchangers, and refinery equipment, while the aerospace and defense sectors use them in high-stress assemblies that demand durability and stability. Even power generation and desalination plants count on these stud bolts for secure fastening. With their strength, reliability, and corrosion resistance, Monel K500 Stud Bolts are truly indispensable for critical operations.
Poang Fasteners is a leading manufacturer and supplier of high-quality fasteners in Da Nang, Vietnam, with over 8 years of experience serving global industries.
