Request For Our Latest Prices On Monel Washers in Da Nang, Vietnam!
Poang Fasteners, located in Da Nang, Vietnam, has made a name for itself as a leading manufacturer and supplier of Monel Washers. These high-quality fastening components are specifically designed to endure even the harshest environments. Renowned for their exceptional resistance to seawater, acids, and alkalis, Monel Washers find their place in various industries, including marine, chemical, oil and gas, and power generation. With a commitment to precision and strict adherence to global standards, Poang Fasteners guarantees that each washer offers dimensional accuracy, impressive strength, and a long service life, making them a trusted choice for critical fastening needs around the globe.
Monel Washers are primarily made from a nickel-copper alloy, usually Monel 400 or Monel K500, with small amounts of iron, manganese, carbon, and silicon added in. This unique composition gives them remarkable corrosion resistance, toughness, and durability in both acidic and alkaline environments. On a mechanical level, Monel Washers boast high tensile and yield strength, excellent fatigue resistance, and stability across a broad temperature range—from cryogenic conditions to high heat. Their ability to resist oxidation and stress corrosion cracking makes them ideal for demanding industrial settings.
|
Element |
Content (%) |
|
Nickel, Ni |
63.00 min |
|
Silicon, Si |
0.5 max |
|
Carbon, C |
0.3 max |
|
Sulphur, S |
0.024 |
|
Copper, Cu |
28-34 |
|
Iron, Fe |
2.5 max |
|
Manganese, Mn |
2 max |
|
Properties |
Metric |
Imperial |
|
Tensile strength(annealed) |
517-620 MPa |
75-90 ksi |
|
Yield strength |
172-345 MPa |
25-50 ksi |
|
Modulus of elasticity |
179 GPa |
26000 ksi |
|
Poisson’s ratio |
0.32 |
0.32 |
| Monel Washers Standard | ASTM B164 / ASME SB164 |
| Monel Washer Dimensions | ASTM, DIN, BS, GB, IS and all International Standards |
| Monel Washers Size Range | M3 – M56 | 3/6″ to 2″ | Custom Sizes |
| Monel Alloy Washers Length | 3 mm to 200 mm |
| SA 164 Monel Washers Marking | All Fasterners are marked as follows: Grade, Standard, Thickness, Heat No. (Or according to the customer’s request.) |
| Delivery Time | 7-15 working days as usual, It will based on the detailed order quantity. |
| Payment Terms | Paypal, Western Union, T/T (Telegraphic Transfer or Wire Transfer), L/C or Trade Assurance 30% deposit & balance before shipping |
To satisfy our clients needs by providing high quality products at competitive price as per the schedule and to maintain long term relationship with our clients.
Monel washers produced by Poang Fasteners are widely used in different applications that require high performance. In marine applications, they are not affected by the corrosive effects of water, thus they have a long life span. In chemical processing they are efficient in handling corrosive materials. In aerospace, they offer safe fastening and insulation where high temperature and high pressure are likely to prevail. Also, Monel washers are applied in oil and gas industries due to their high strength and ability to work in harsh conditions.
These washers are widely used in shipbuilding, offshore structures, and marine equipment, where resistance to seawater is crucial. In the chemical and petrochemical sectors, they are found in pumps, heat exchangers, valves, and other process equipment that come into contact with corrosive substances. The oil and gas industry utilizes them in refineries, drilling rigs, and subsea operations, while power generation and desalination plants rely on them for high-pressure, high-temperature applications. Additionally, industries like aerospace, defense, and heavy machinery trust Monel Washers for their reliability and durability. Their versatility and resistance to corrosion make them essential across a variety of sectors.
Poang Fasteners is a leading manufacturer and supplier of high-quality fasteners in Da Nang, Vietnam, with over 8 years of experience serving global industries.
