Request For Our Latest Prices On ZERON 100 Bolts in Da Nang, Vietnam!
Poang Fasteners is a well-respected manufacturer and supplier of ZERON 100 Bolts based in Da Nang, Vietnam. We specialize in providing top-notch fastening solutions designed to withstand extreme conditions. ZERON 100 is a super duplex stainless steel alloy that boasts impressive strength and remarkable resistance to corrosion, especially in seawater, chlorides, and harsh chemicals. Our bolts are crafted to meet international standards like ASTM, DIN, and ISO, ensuring they are built for durability and reliability. You’ll find Poang ZERON 100 Bolts in various applications, including offshore oil & gas, desalination plants, chemical processing, marine projects, and power generation, where safety and performance are paramount.
Poang ZERON 100 Bolts are crafted from a super duplex stainless steel alloy that includes about 25% chromium, 7% nickel, 3.6% molybdenum, 0.7% copper, along with tungsten and nitrogen. This carefully balanced composition offers exceptional resistance to pitting, crevice corrosion, and stress corrosion cracking in environments rich in chlorides. They provide impressive tensile strength (around 800–850 MPa), yield strength (approximately 550 MPa), and outstanding impact toughness. ZERON 100 also maintains excellent dimensional stability under high pressures and temperatures, along with remarkable fatigue resistance. These qualities make ZERON 100 Bolts perfect for critical applications that require reliability, strength, and long-lasting resistance to tough environmental conditions.
| % | Cr | Ni | Mo | Cu | W | C | N | Mn | Si | P | S | Fe |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Min | 24 | 6 | 3 | 0.5 | 0.5 | – | 0.2 | – | – | – | – | – |
| Max | 26 | 8 | 4 | 1 | 1 | 0.03 | 0.3 | 1 | 1 | 0.030 | 0.010 | Balance |
| Mechanical & Physical Properties | -70°C | -46°C | 21.1 °C | 93.3°C | 148.9 °C | 204.4 °C | 250 °C | 300°C |
|---|---|---|---|---|---|---|---|---|
| Ultimate Tensile Strength, MPa | – | – | 750 | 670 | 620 | 610 | 600 | 590 |
| 0.2% Yield Strength, MPa | – | – | 550 | 430 | 400 | 380 | 370 | 360 |
| Reduction of area % | – | – | – | – | – | – | – | – |
| Elongation % | – | – | 25 | – | – | – | – | – |
| UNS S32760 Fg Bolts, Studs Threads: | METRIC, BSW, BSF, UNC, UNF or as required |
|---|---|
| Zeron 100 Threaded Rod Standard: | ANSI – American National Standards Institute
|
| Zeron 100 Fasteners Material Specification | Zeron 100 Fasteners , UNS S32760 Bolts |
| S32760 Fasteners / Bolts Standard | DIN, UNI, ISO, JIS, GB, IS, BS, ASME, ANSI, ASTM and all International Standards |
| 1.4501 UNS S32760 Fasteners/ Bolts Size | M2, M2.5, M3, M4, M5, M6, M8, M10, M12, M14, M16, M20, M24, M30, M36 to M160 |
| Length of S32760 Hex Bolt | 3 mm to 200 mm |
| Source of raw materials to manufacture 1.4501 UNS S32760 Screw | Tata Steel, JSPL, RINL, Usha Martin, Dhamm Steel, Mukund Steel etc. |
| Zeron 100 Hex Bolt Thread | Metric Coarse |
| S32760 bolting Test Certificate: | Manufacturer Test Certificate as per EN 10204 / 3.1 |
To satisfy our clients needs by providing high quality products at competitive price as per the schedule and to maintain long term relationship with our clients.
Poang ZERON 100 Bolts are a top choice in industries that face aggressive, high-stress environments. Offshore oil & gas platforms rely on them for subsea equipment, pipelines, and risers, thanks to their exceptional resistance to seawater corrosion. In desalination plants, they are used to secure high-pressure vessels and pumps that deal with brine. The chemical and petrochemical sectors utilize them in heat exchangers, reactors, and storage tanks that handle acidic and chloride-rich solutions. Power plants and marine engineering projects also benefit from these bolts, ensuring safety and performance in demanding conditions.
