Request For Our Latest Prices On ASTM A182 F60 Fasteners in Da Nang, Vietnam!
Poang Fasteners, a well-respected manufacturer and supplier located in Da Nang, Vietnam, is dedicated to providing top-notch ASTM A182 F60 Fasteners for a variety of industries. Crafted from duplex stainless steel grade F60, these fasteners are celebrated for their remarkable strength and resistance to corrosion. Built to endure tough conditions, ASTM A182 F60 Fasteners find their place in chemical processing, offshore platforms, marine structures, and power generation projects. Poang is committed to upholding international standards, offering a range of bolts, nuts, screws, studs, and washers that ensure durability, reliability, and a long lifespan in critical applications.
ASTM A182 F60 Fasteners consist of around 25% chromium, 7% nickel, 4% molybdenum, along with nitrogen additions that boost both corrosion and pitting resistance. This duplex stainless steel features a well-balanced microstructure of austenite and ferrite, which gives it superior mechanical properties compared to standard stainless steels. With a tensile strength of approximately 655 MPa and a yield strength of 450 MPa, these fasteners provide excellent toughness and resistance to stress corrosion cracking. The careful balance of chemical and mechanical properties ensures high performance in aggressive environments, such as seawater and chloride-rich conditions.
| Identification Symbol | UNS Number | Grade | Elements | Composition % |
|---|---|---|---|---|
| F60 | S32205 | 22 chromium, 5.5 nickel, 3 molybdenum, modified with nitrogen 2205 | Carbon | 0.030 max |
| Manganese | 2.00 max | |||
| Phosphorus | 0.030 max | |||
| Sulfur | 0.020 max | |||
| Silicon | 1.00 max | |||
| Nickel | 4.5 – 6.5 | |||
| Chromium | 22.00 – 23.00 | |||
| Molybdenum | 3.00 – 3.5 | |||
| Nitrogen | 0.14 – 0.20 |
| Property | Value |
|---|---|
| Tensile Strength, min, ksi [MPa] | 95 [655] |
| Yield Strength, min, ksi [MPa] | 65 [450] |
| Elongation in 2 in. [50mm] or 4D, min, % | 25 |
| Reduction or Area, min, % | 45 |
| Brinell Hardness Number, HBW | — |
| Standard | ASTM, BS, ASME, ISO, UNI, ANSI, GB, IS, DIN, JIS Fasteners |
|---|---|
| Threads: | BSF, BSW, UNF, UNC, METRIC or as per need |
| Astm A182 Grade F60 Bolts Standard | ANSI
|
| ASTM A182 GR. F60 Fasteners / Bolts Size | M6, M30, M12, M10, M16, (M45), M4, M8, M2, M24, (M3.5), M33, M20, M42, (M14), M5, M48, (M18), (M27), (M22), M36, M3, M160 and as per need |
| Length | 3 milimeter – 200 milimeter |
| Head drive: | Slotted, Six-Lobe, Phillips/Slot, Phillips, etc |
| Bolts Test Certificate | EN 10204 / 3.1 |
| Duplex Grade F60 Fasteners raw materials of Source | Usha Martin, JSPL, Mukund Steel, Tata Steel, Dhamm Steel, RINL etc. |
| Form | Square, Hex, Threading as per Gauge, Round Etc. |
| Astm A182 Grade F60 Bolts Process of Production |
|
| Duplex Steel Gr F60 Fasteners Surface Coating |
|
To satisfy our clients needs by providing high quality products at competitive price as per the schedule and to maintain long term relationship with our clients.
ASTM A182 F60 fasteners are utilized across industries requiring exceptional corrosion resistance and mechanical strength. They find application in demanding environments such as offshore oil rigs, chemical processing plants, and marine structures. These fasteners are crucial for securing critical components where resistance to chloride-induced stress corrosion cracking is vital. With their high tensile strength and durability, ASTM A182 F60 fasteners ensure reliable performance in harsh conditions, making them preferred choices for ensuring structural integrity and longevity in challenging operational settings.
The versatility of ASTM A182 F60 Fasteners spans across various industries that demand strength and corrosion resistance in challenging environments. In the oil and gas sector, they are essential for pipeline connections, pressure vessels, and subsea equipment. The marine industry relies on them for shipbuilding, offshore drilling rigs, and seawater desalination plants. They also play a crucial role in the chemical and petrochemical sectors for reactors, heat exchangers, and processing units that come into contact with corrosive chemicals. Furthermore, power generation plants utilize these fasteners in turbines and structural assemblies. Their durability and ability to withstand harsh conditions make them indispensable in these applications.
Poang Fasteners is a leading manufacturer and supplier of high-quality fasteners in Da Nang, Vietnam, with over 8 years of experience serving global industries.
